BTECH UV-5X3 Tri-Band Amateur Radio

Rated 4.81 out of 5 based on 16 customer ratings

(16 customer reviews)

$64.89

BTECH UV-5X3 Tri-Band Radio: High-Power Amateur Handheld with USB-C Charging – VHF, 1.25M, UHF – Customizable Features – Comprehensive Accessory Bundle Included

CHARGING PLUG ADAPTER

Clear

From the manufacturer

BTECH UV-5X3: Engineered for Superior Performance and Resilience

Familiar Case, but a Fully Upgraded Radio

When selecting a radio for your communication needs, you deserve a product that offers not just basic features but advanced capabilities, robust construction, and premium performance. BTECH’s UV-5X3 stands out as a perfect embodiment of this principle.

Don’t be fooled by its familiar exterior; we’ve significantly updated and upgraded the UV-5X3 while maintaining full backward accessory compatibility. We believe in progress, but not at the expense of convenience and value.

Tailored for Amateur Bands

Unlike many radios that aim for ‘general-purpose’ performance, the UV-5X3 is specifically fine-tuned for optimal performance in amateur bands. This translates into superior reception and transmission quality, ensuring that your voice is clearly heard and messages received with unrivaled clarity.

Future-Focused Charging

The UV-5X3 utilizes a USB-C rechargeable battery, a standard that’s quickly becoming the norm. This universal compatibility allows you to charge your device from multiple sources, bypassing the need for specific cables or adapters.

From the manufacturer

IP54 Weather Resistant

Snow, rain, or shine you can feel free to use your UV-5X3 radio no matter what the weather conditions are. The UV-5X3 is weather resistant and splash proof.

Unmatched Tri-Band Versatility

A step above the average dual-band radios, the UV-5X3 brings the game-changing advantage of tri-band functionality. It operates on VHF, 1.25M, and UHF frequencies, offering an extended range of communication possibilities. This broader spectrum allows you to connect over different frequency bands, ensuring clear and robust signals in a variety of scenarios. Whether you’re coordinating with a team during emergency responses, tuning into local weather stations, or simply keeping in touch with fellow amateur enthusiasts, the UV-5X3’s tri-band versatility ensures reliable and flexible communication. This is not just a feature; it’s a significant upgrade that empowers you to communicate more efficiently and effectively.

BTECH BL-5 USB-C Charging

The BL-5 battery now includes USB-C charging, providing users with greater flexibility and convenience in powering their devices. With this feature, you can charge the battery directly using a USB-C cable, or you can still use the CH-5 desktop charger if you prefer.

The USB-C charging feature makes it easy to charge your BL-5 battery on the go, using a power bank or a laptop with a USB-C port. This means you no longer have to rely on the CH-5 desktop charger, which may not always be available or convenient to use.

Revolutionary Remote Capabilities

The BTECH UV-5X3 sets itself apart with a set of remote functions designed to give you total control over your communication devices, even at a distance. With the Stun and Kill functions, you can remotely disable a radio – a crucial feature in managing potential security situations. Need to re-enable a stunned radio? The Revive function brings it back to life with a simple command.

Moreover, the Inspect function adds another layer of control to your operations. By sending a simple command, you can confirm if a radio is within your range as it replies with a confirmation tone. Not only does this facilitate seamless coordination, but it also assists in ensuring all your team members are within communication boundaries.

Finally, the Monitor function can be remotely activated to silently monitor the environment around the radio. This feature is especially beneficial in situations where stealth or silent observation is necessary.

From the manufacturer

Display Synchronization

An exciting, new feature on the UV‑5X3 takes full advantage of the LCD’s dual line display. In the past the dual display allowed you to monitor two different frequencies at once. Unfortunately, for user’s that only wanted to monitor a single channel, the secondary line was of no use… until the UV‑5X3!

The UV‑5X3 allows users, who want to display the most information at once, to synchronize the display. This allows the LCD to show both the channel’s frequency and channel name simultaneously. Display synchronization allows the user to maximize the available information seen at a glance!

Modify the Scanning List

A brand new menu allows for one of the biggest conveniences while scanning: Modifying the Scanning List!

Before the UV‑5X3, you couldn’t manage the channel scan list without a computer. The brand new menu in the UV‑5X3 allows you to easily add and remove channels from the scanning list. Have a nuicanse channel that you want removed from the scan list? You no longer need to go home to a computer to remove it: A simple menu allows you modify your channel scan list without a computer

Channel Mode Modifications

The UV‑5X3 comes out of the rut that all other UV‑5 series radios are stuck in. The UV‑5X3, built with the amateur radio operator in mind, allows channel modifications on-the-fly.

Previously and on other current UV‑5 models, you were forced to delete a channel and then recreate it from scratch if you wanted to alter any settings.

The UV‑5X3 allows common edits to the channels: Such as adding, changing, or removing the privacy tones (CTCSS & DCS); or changing the power level. You no longer have to delete and recreate the channel over simple channel modifications.

Scan a Frequency Range

Scanning in frequency mode, just became practical! Exclusively on the BTECH UV‑5X3: You are able to scan through a specific frequency range.

Scanning frequencies before the UV‑5X3 required the user to scan the full frequency band they were using. This was not practical if you only wanted to watch for activity on a particular section of the band (such as only 222-225MHz in the above pictured example). The UV‑5X3 will scan at the frequency step you select in menu, which allows you to scan by increments from 2.5 to 50KHz. You can now scan through a fine tuned portion of the receiving band without having to wait and scan the whole band!

Technical Specifications

Frequency Range	VHF / 1.25M / UHF / FM Radio (RX Only on FM)
Memory Channel	128 Channels
Output power	5W/.5W
Privacy Tones (PL/DPL)	All CTCSS and DCS tones are supported.

Accessory Jack	K1 Kenwood 2 Pin Jack
Additional Features	Display Sync, Nuisance Channel Scan Skip, SOS Alarm, NOAA Weather Channels, Transmit Time-Out, Busy Channel Lockout, DTMF Keypad, Adjustable Scanning Modes, Dual Watch, Adjustable Squelch
Weatherproof Rating	IP54 Weather Resistant
Chassis Accessories	Compatible with all UV-5R and BF-F8HP Chassis Accessories

UV-5X3: A Better Receiver than our Imitators!

Unlike our peers we do not take an existing radio off the shelf and simply apply ‘a different firmware’. The UV-5X3 was from the ground up – built for Amateur Users! It takes time to properly build a product dedicated for a specific purpose. A properly designed radio, means that the receiver and transmitter will outperform in clarity, reach, and performance in comparison to those other radios that simply had that magic ‘firmware flash’.

Common Questions and Answers:

Q: What is the charge and usage time?
A: The radios will fully charge in 3-4 hours, and the battery will last 18 hours on normal usage.
Q: What is the maximum range?
A: Range varies on topography: Repeater Use: Up to 100 miles | Hill to Valley: 36 miles | Open Flat Terrain: 3-5 miles | Urban/Outside Buildings: ~1 mile
Q: Is it Computer or User Programmable
A: Yes it is fully front panel programmable, as well as computer programmable and fully supports CHIRP (a free radio programming software)

BTECH: We are proud to be here in the USA

BTECH radios are designed and supported right here in the USA. A BTECH label means you are getting a radio with real US based support, and development! If you ever have an issue, our team will be prompt, knowledgeable, and supportive to ensure your radio operates exactly as it should.

Product Description

BTECH UV-5X3 Tri-Band Radio: High-Power Amateur Handheld with USB-C Charging – VHF, 1.25M, UHF – Customizable Features – Comprehensive Accessory Bundle Included
